Inspection, Integrity and Corrosion

Pipeline Welding and Inspection to API 1104

On a cross country pipeline the girth weld is made in the open, often downhill, by a spread of welders advancing several kilometres each week, and every joint must pass before the ditch is closed. API 1104 governs that work. Delegates start with procedure qualification for cellulosic stick, low hydrogen and mechanised welding, and the changes that force requalification, then move to welder qualification by single and multiple qualification tests. Nick break, root bend and face bend specimens are interpreted on real samples. The production acceptance standards for radiography and automated ultrasonic testing are covered defect by defect, followed by welding on pressurised lines, hot tap fittings, burn through and hydrogen cracking. The final session introduces alternative acceptance criteria based on engineering critical assessment, and the girth weld records a spread should keep.

5 day course

Course objectives

  • Explain the scope of API 1104 for new construction and in service pipeline welding
  • Qualify a welding procedure for cellulosic, low hydrogen or mechanised girth welds
  • Identify the essential variables that require pipeline procedure requalification
  • Plan single and multiple welder qualification tests
  • Interpret nick break, root bend and face bend specimens
  • Apply the acceptance standards for radiographic and automated ultrasonic testing
  • Evaluate burn through and hydrogen cracking risk when welding onto live lines
  • Describe when engineering critical assessment acceptance criteria may be used

Who should attend

  • Pipeline construction engineers
  • Welding inspectors on pipeline spreads
  • Pipeline contractors' quality managers
  • Gas and liquids pipeline operators' integrity engineers
  • Hot tap and in service welding supervisors

Course outline

  1. 01Scope of API 1104 and pipeline welding practice
  2. 02Procedure qualification for girth welds
  3. 03Essential variables and requalification
  4. 04Welder qualification tests
  5. 05Nick break and bend testing
  6. 06Radiographic acceptance standards
  7. 07Automated ultrasonic testing of girth welds
  8. 08Welding on pressurised lines and hot tap fittings
  9. 09Alternative acceptance criteria

Scheduled sessions

Scheduled sessions for Pipeline Welding and Inspection to API 1104
DatesVenueFormatPriceRegister
19 to 23 October 2026Harare, ZimbabweClassroomUSD 1,325 per delegate
2 to 6 November 2026Windhoek, NamibiaClassroomR19,950 per delegate
23 to 27 November 2026OnlineOnlineR8,500 per delegate
30 November to 4 December 2026Maseru, LesothoClassroomR19,950 per delegate
14 to 18 December 2026Nairobi, KenyaClassroomUSD 1,325 per delegate
21 to 25 December 2026Pretoria, South AfricaClassroomR19,950 per delegate
