Power and ElectricalElectrical Power System Analysis and Design
This course covers the studies that underpin the design and operation of an electrical network. Delegates work through load flow analysis, short circuit study, motor starting and voltage dip assessment, harmonic analysis, and arc flash study, and learn to set up each study correctly, interpret the output and act on it. Emphasis is placed on the modelling assumptions that determine whether a study result is meaningful, because most study errors originate in the data rather than the software. Delegates finish able to specify a study, review a consultant's output critically and translate results into design or operational decisions.
Course objectives
- Set up and interpret a load flow study
- Perform short circuit calculations and apply the results to equipment rating
- Assess motor starting and voltage dip on a network
- Carry out harmonic analysis and evaluate mitigation
- Interpret an arc flash study and its assumptions
- Identify modelling assumptions that invalidate a study
- Review a consultant's study output critically
Who should attend
- Electrical design and system engineers
- Consulting engineers
- Utility planning engineers
- Industrial electrical engineers
- Technical staff commissioning or reviewing network studies
Course outline
- 01Network modelling and the data that determines study validity
- 02Load flow analysis and interpretation
- 03Short circuit study and equipment rating
- 04Motor starting and voltage dip assessment
- 05Harmonic analysis and mitigation
- 06Arc flash study and its assumptions
- 07Translating study results into design decisions
- 08Reviewing a consultant's output critically
Scheduled sessions
| Dates | Venue | Format | Price | Register |
|---|---|---|---|---|
| 8 to 12 September 2026 | Victoria, Seychelles | Classroom | R11,995 per delegate | Register Now |
| 16 to 20 September 2026 | Maputo, Mozambique | Classroom | R11,995 per delegate | Register Now |
| 4 to 8 October 2026 | Dar es Salaam, Tanzania | Classroom | R11,995 per delegate | Register Now |
| 8 to 12 October 2026 | Port Louis, Mauritius | Classroom | R11,995 per delegate | Register Now |
