Power and ElectricalElectrical Power Distribution and Protection Coordination
A three day course on designing an industrial distribution network and setting the protection that makes it selective. Delegates work through medium and low voltage system design, fault current and short circuit calculation, and the selection of relays, fuses and circuit breakers for each part of a network. Coordination is the heart of the course: delegates build and interpret time current grading curves, so that a fault clears at the device nearest to it rather than tripping half the plant. Earthing, bonding and system grounding are covered as design decisions with direct safety consequences, and the course closes on switchgear selection and protection testing, addressing the switchgear and coordination problems commonly found on industrial sites across the region.
Course objectives
- Design medium and low voltage distribution networks for industrial facilities
- Select and coordinate protective relays, fuses and circuit breakers
- Perform fault current calculations for distribution system protection
- Interpret protection coordination curves and time current grading studies
- Apply earthing and bonding principles to distribution system design
- Set earth fault and differential protection for transformers and feeders
- Investigate a mis operation and correct the settings that caused it
Who should attend
- Electrical engineers
- Protection engineers
- Substation engineers
- Plant electrical supervisors
- Design engineers working on distribution projects
Course outline
- 01Medium and low voltage distribution system design
- 02Fault current analysis and short circuit calculations
- 03Protective relay types and application
- 04Protection coordination and time current grading
- 05Earth fault, differential and transformer protection
- 06Earthing, bonding and system grounding
- 07Switchgear selection and protection testing
- 08Investigating relay mis operation and correcting settings
Scheduled sessions
| Dates | Venue | Format | Price | Register |
|---|---|---|---|---|
| 11 to 13 November 2026 | Gaborone, Botswana | Classroom | R14,950 per delegate | Register Now |
| 11 to 13 January 2027 | Online | Online | R6,500 per delegate | Register Now |
| 17 to 19 February 2027 | Durban, South Africa | Classroom | R14,950 per delegate | Register Now |
| 29 to 31 March 2027 | Mbabane, Eswatini | Classroom | R14,950 per delegate | Register Now |
