Power and ElectricalArc Flash Study and Calculation
An arc flash study converts a network model into the incident energy a worker would be exposed to at each point, and the result governs what they may wear and how they may work. This course covers producing one. Delegates work through the physics of an arcing fault, the data collection that determines whether a study means anything, and short circuit and protection coordination as the prerequisites. Incident energy calculation is worked through by hand before any software, so delegates understand what drives the result, particularly clearing time. Labelling, protective equipment selection and the working practices that reduce exposure follow, and the course closes on maintaining a study as a network changes.
Course objectives
- Explain the physics of an arcing fault and what drives incident energy
- Collect the data a study depends on and recognise when it is inadequate
- Complete short circuit and coordination study prerequisites
- Calculate incident energy and arc flash boundary by hand
- Interpret how clearing time dominates the result
- Produce labels and select protective equipment from the result
- Maintain a study as the network changes
Who should attend
- Electrical engineers and safety engineers
- Protection and design engineers
- Electrical safety officers and authorising officers
- Maintenance managers
- Consultants producing arc flash studies
Course outline
- 01The physics of an arcing fault
- 02Data collection and study validity
- 03Short circuit study prerequisites
- 04Protection coordination and clearing time
- 05Incident energy calculation by hand
- 06Arc flash boundary and labelling
- 07Protective equipment selection
- 08Reducing exposure, and maintaining the study
Scheduled sessions
| Dates | Venue | Format | Price | Register |
|---|---|---|---|---|
| 2 to 4 November 2026 | Harare, Zimbabwe | Classroom | USD 995 per delegate | Register Now |
| 11 to 13 November 2026 | Online | Online | R6,500 per delegate | Register Now |
| 11 to 13 January 2027 | Accra, Ghana | Classroom | USD 995 per delegate | Register Now |
| 18 to 20 January 2027 | Cape Town, South Africa | Classroom | R14,950 per delegate | Register Now |
